ROTARY DAMPERS

C SERIES
Rotary damper two way
SUBSERIES CD

Description

CE series has front clip and collar mounting feature, a body diameter of 15 mm and available torque from 0.12 Ncm to 2.20 Ncm. Many gear wheels are available and customizations of torque or color are possible. Snap-on clips mounting are suitable for a very efficient and simple manual or automatic assembly.

TORQUE (ncm):

0,12 - 2,20 Ncm @ 20rpm/RT

Torque schema 0,12 - 2,20 Ncm @ 20rpm/RT
DIAMETER:

14,95

DIRECTION:

two ways

TECHNICAL MATERIAL:

POM (rotor) + PA66GF13 (base) + POM gear + silicone oil

MATERIAL:

plastic

CLIP:

front clips

HOLES:

-

Applications

Main applications are headrests, central console, glasses drawer, bins, central armrest, ashtray, mobile phone holder, fuel door, as well as shelves for hand luggage for airplanes, helmet visors, hi-fi systems, displays and vending machines, desk sockets, robotics applications, precision instruments, covers for 3D printers and scanners, joysticks, coffee machines, vacuum cleaners, oven hinges and any other small or medium weight rotary application.

Let's slow the world down

Cultraro is a world leader in the production of rotary, axial, linear dampers and push-push latches to slow down the opening / closing movements of different products and improve the quality of their operation in various technical applications.

Img Datasheet
Img 3D Model
